S811+ Operating Configuration
34 S811+ Soft Starter MN03900001E—November 2012
Operating Parameters—Soft Start Configuration—S811+ …V3S Premium (690 Volt)
Soft Start Config Menu Units
Minimum
Inline
Maximum
Inline
Default
Inline Notes
Access
Level
Mtr Nameplate FLA 2
S811+T18… Amps 56 180 56 Motor FLA parameter must be set to motor
nameplate FLA to achieve proper overload
protection.
2
S811+T24… Amps 75 240 75 2
S811+T30… Amps 95 304 95 2
S811+V36… Amps 112 360 112 2
S811+V42… Amps 131 420 131 2
S811+V50… Amps 156 500 156 2
S811+V65… Amps 203 650 203 2
S811+V72… Amps 225 720 225 2
S811+V85… Amps 265 850 265 2
Ovrld Trip Class 5 30 20 2
Phase Rev Fault 0 1 0 0 = Enabled
1 = Disabled
2
Phase Sequence 0 1 0 0 = ABC
1 = ACB
2
Start Method 0 3 0 0 = Voltage Ramp
1 = Current Limit
2 = Unavailable
3 = Pump Start
2
Initial Torque % 0 85 45 1
Soft Start Time Seconds 0.5 360 20 1
Kick Start Torq % 0 85 0 1
Kick Start Time Seconds 0 2 0 1
Pump Stop Time Seconds 5 120 10 1
Soft Stop Time Seconds 0 60 0 1
Reset Mode 0 2 0 0 = Manual
1 = Auto
2 = Powerup Reset
2
Auto Reset Delay Seconds 0.1 600 0.1 2
Auto Reset Limit 0 10000 0 2
Motor Wiring Config 0 0 0 0 = Inline 2
