Technical Data and Specifications
S811+ Soft Starter MN03900001E—November 2012 5
Short-Circuit Information with IEC Breakers
Note: For more details on short-circuit protector selections and enclosure sizing, please refer
to the linked spreadsheet on UL’s website at: http://www.ul.com/global/documents/
offerings/industries/buildingmaterials/industrialcontrolpanels/shortcut.Eaton.xls
Note: Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 600 volts maximum when protected by Class RK5 fuses.
Note: Suitable for use on a circuit capable of delivering not more than 65,000 rms
symmetrical amperes, 480 volts maximum when protected by a circuit breaker.
Catalog
Number
Prefix
Starter—
Maximum
Rated
Operational
Current
(Standard
Duty)
Motor
Current—
Based Upon
Maximum
Operational
Voltage of
400 Vac
Four-Pole
Motor kW at
400V 50 Hz
Short Circuit
Rating at
400V 50 Hz
Motor
Current—
Based Upon
Maximum
Operational
Voltage of
690 Vac
Four-Pole
Motor kW at
690V 50 Hz
Short Circuit
Rating at
690V 50 Hz
Recommended
Mag—Only
Breaker for
IEC Markets[A] [A] [kW] [kA] [A] [kW] [kA]
S811+N37… 37 34.9 18.5 50
These devices do not have 690 Vac ratings
NZMN1-S40
S811+N66… 66 55.5 30 50 NZMN1-S63
S811+R10… 105 99.7 55 50 NZMN1-S100
S811+R13… 135 135 75 50 NZMN2-S160
S811+T18… 180 161 90 50 163 160 18 NZMN2-S200
S811+T24… 240 196 110 50 253 250 18 NZMN2-S200
S811+T24… 240 231 132 50 253 250 18 NZMN3-S250
S811+T30… 304 279 160 50 303 300 18 NZMN3-S320
S811+V36… 360 351 200 50 357 355 20 NZMN3-S400
S811+V42… 420 351 200 50 357 355 20 NZMN3-S400
S811+V50… 500 437 250 50 500 500 20 NZMN3-S500
S811+V65… 650 544 315 50 628 630 20 NZMN4-ME875
S811+V72… 720 683 400 50 706 710 20 NZMN4-ME875
S811+V85… 850 769 450 50 844 850 20 NZMN4-ME875
S811+V10… 1000 863 500 50 991 1000 20 NZMN4-ME1400
