Eaton SVX9000 Series - Dimensions; NEMA Type 1 and NEMA Type 12 9000 X Drive Dimensions, FR4, FR5 and FR6

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
15
SVX9000 Adjustable Frequency Drives
Open Drives
Dimensions
Figure 2. NEMA Type 1 and NEMA Type 12 9000X Drive Dimensions, FR4, FR5 and FR6
Table 28. 9000X Drive Dimensions
Frame
Size
Voltage hp (I
H
) Approximate Dimensions in Inches (mm) Weight
Lbs.
(kg)
Knockouts @ Inches (mm)
H1 H2 H3 D1 D2 D3 W1 W2 W3 R1 dia. R2 dia. N1 (O.D.)
FR4 230V 3/4 – 3 12.9
(327)
12.3
(313)
11.5
(292)
7.5
(190)
3.0
(77)
5.0
(126)
5.0
(128)
3.9
(100)
— .5
(13)
.3
(7)
11.0
(5)
3 @ 1.1
(28)
480V 1 – 5
FR5 230V 5 – 7-1/2 16.5
(419)
16.0
(406)
15.3
(389)
8.4
(214)
3.9
(100)
5.8
(148)
5.6
(143)
3.9
(100)
— .5
(13)
.3
(7)
17.9
(8)
2 @ 1.5
(37)
1 @ 1.1
(28)
480V 7-1/2 – 15
FR6 230V 10 – 15 22.0
(558)
21.3
(541)
20.4
(519)
9.3
(237)
4.2
(105)
6.5
(165)
7.6
(195)
5.8
(148)
— .6
(15.5)
.4
(9)
40.8
(19)
3 @ 1.5
(37)
480V 20 – 30
575V 2 – 25
EATON
D1 W2
W1
R2
R1
R2
H3
H2
H1
D2
D3
Knockouts
W3
