Eaton SVX9000 Series - 9000 X Dimensions, NEMA Type 1 and NEMA Type 12 FR9

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
21
SVX9000 Adjustable Frequency Drives
Open Drives
Figure 8. 9000X Dimensions, NEMA Type 1 and NEMA Type 12 FR9
Table 36. Dimensions for 9000X, FR9

Brake resistor terminal box (H6) included when brake chopper ordered.
D2
Dia.
D1
H5
W2
W4
H3
H4
H2
H1
H6
W3
W5
PE
B- B+ /R+ R-
W5
W1
D3
Frame
Size
Approximate Dimensions in Inches (mm)
W1 W2 W3 W4 W5 H1 H2 H3 H4 H5 H6

D1 D2 D3 Dia.
FR9 18.9
(480)
15.7
(400)
6.5
(165)
.4
(9)
2.1
(54)
45.3
(1150)
44.1
(1120)
28.3
(721)
8.0
(205)
.6
(16)
7.4
(188)
14.2
(361.5)
13.4
(340)
11.2
(285)
.8
(21)
