Eaton SVX9000 Series User Manual

CA04000006E For more information visit: www.EatonElectrical.com
9
SVX9000 Adjustable Frequency Drives
June 2006
Open Drives
575V SVX9000 Drives
Table 12. 525 – 690V, NEMA Type 1 Drive
Table 13. 525 – 690V, NEMA Type 1 Freestanding Drive
Note: Integrated fuses as standard. Limited option selection available; 115V Transformer (KB),
Light Kit (L1), HOA (K4), Speed Potentiometer w/HOA (K2), Disconnect Switch (P2). See
Enclosed 480V option selection.
Table 14. 525 – 690V, NEMA Type 12 Drive
Frame
Size
Delivery
Code
hp (I
H
) Current
(I
H
)
hp (I
L
) Current
(I
L
)
Catalog
Number
Price
U.S. $
FR6 W 2
3
—
5
7-1/2
10
15
20
25
3.33
4.5
5.5
7.5
10
13.5
18
22
27
3
—
5
7-1/2
10
15
20
25
30
4.5
5.5
7.5
10
13.5
18
22
27
34
SVX002A1-5A4N1
SVX003A1-5A4N1
SVX004A1-5A4N1
SVX005A1-5A4N1
SVX007A1-5A4N1
SVX010A1-5A4N1
SVX015A1-5A4N1
SVX020A1-5A4N1
SVX025A1-5A4N1
2,065.
2,285.
2,495.
2,865.
3,555.
4,395.
5,240.
6,040.
6,960.
FR7 W 30
40
34
41
40
50
41
52
SVX030A1-5A4N1
SVX040A1-5A4N1
7,970.
8,730.
FR8 W 50
60
75
52
62
80
60
75
100
62
80
100
SVX050A1-5A4N1
SVX060A1-5A4N1
SVX075A1-5A4N1
9,590.
12,440.
15,900.
FR9 W 100
125
150
—
100
125
144
170
125
150
—
200
125
144
170
208
SVX100A1-5A4N1
SVX125A1-5A4N1
SVX150A1-5A4N1
SVX175A1-5A4N1
17,470.
21,730.
23,290.
23,970.
Frame
Size
Delivery
Code
hp (I
H
) Current
(I
H
)
hp (I
L
) Current
(I
L
)
Catalog
Number
Price
U.S. $
FR10 FP 200
250
300
208
261
325
250
300
400
261
325
385
SPX200A1-5A4N1
SPX250A1-5A4N1
SPX300A1-5A4N1
35,020.
45,020.
71,140.
FR11 FP 400
450
500
385
460
502
450
500
550
460
502
590
SPX400A1-5A4N1
SPX450A1-5A4N1
SPX500A1-5A4N1
91,220.
104,340.
121,460.
Frame
Size
Delivery
Code
hp (I
H
) Current
(I
H
)
hp (I
L
) Current
(I
L
)
Catalog
Number
Price
U.S. $
FR6 F1 2
3
—
5
7-1/2
10
15
20
25
3.33
4.5
5.5
7.5
10
13.5
18
22
27
3
—
5
7-1/2
10
15
20
25
30
4.5
5.5
7.5
10
13.5
18
22
27
34
SVX002A2-5A4N1
SVX003A2-5A4N1
SVX004A2-5A4N1
SVX005A2-5A4N1
SVX007A2-5A4N1
SVX010A2-5A4N1
SVX015A2-5A4N1
SVX020A2-5A4N1
SVX025A2-5A4N1
2,390.
2,610.
2,820.
3,195.
3,895.
4,735.
5,590.
6,390.
7,320.
FR7 FP 30
40
34
41
40
50
41
52
SVX030A2-5A4N1
SVX040A2-5A4N1
8,690.
9,440.
FR8 FP 50
60
75
52
62
80
60
75
100
62
80
100
SVX050A2-5A4N1
SVX060A2-5A4N1
SVX075A2-5A4N1
10,810.
13,690.
17,170.
FR9 FP 100
125
150
—
100
125
144
170
125
150
—
200
125
144
170
208
SVX100A2-5A4N1
SVX125A2-5A4N1
SVX150A2-5A4N1
SVX175A2-5A4N1
20,120.
24,420.
25,990.
26,670.
Discount Symbol. . . . . . . . . . . . . . . . . . . . . . . . SS-2

Eaton SVX9000 Series Specifications

General

Communication Protocols	Modbus RTU, CANopen
Protection Features	Overcurrent, Overvoltage, Short Circuit, Over Temperature
Cooling Method	Forced Air Cooling
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
