Eaton SVX9000 Series - 9000 X Dimensions, NEMA Type 1 and NEMA Type 12, with Flange Kit, FR7 and FR8

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
19
SVX9000 Adjustable Frequency Drives
Open Drives
Figure 6. 9000X Dimensions, NEMA Type 1 and NEMA Type 12, with Flange Kit, FR7 and FR8
Table 33. Dimensions for 9000X, FR7 and FR8 with Flange Kit
Table 34. Dimensions for the Flange Opening, FR7/FR8
H7
W3
H9
D1
W1
H9H12
H13
H11H10
H1
H2
H5
Dia. A
Dia. B
H4H4H6
W2
W4
D2
W6W5
W7
H3
H8
Flange Opening
FR7/FR8
Frame
Size
Approximate Dimensions in Inches (mm)
W1 W2 W3 W4 H1 H2 H3 H4 H5 H6 H7 D1 D2 Dia. A
FR7 9.3
(237)
6.8
(175)
10.6
(270)
10.0
(253)
25.6
(652)
24.8
(632)
24.8
(630)
7.4
(189)
7.4
(189)
.9
(23)
.8
(20)
10.1
(257)
4.6
(117)
.3
(6)
FR8 11.2
(285)
— 14.0
(355)
13.0
(330)
32.8
(832)
— 29.3
(745)
10.2
(258)
10.4
(265)
1.7
(43)
2.2
(57)
13.5
(344)
4.3
(110)
.4
(9)
Frame
Size
Approximate Dimensions in Inches (mm)
W5 W6 W7 H8 H9 H10 H11 H12 H13 Dia. B
FR7 9.2
(233)
6.9
(175)
10.0
(253)
24.4
(619)
7.4
(189)
7.4
(189)
1.4
(35)
1.3
(32)
1.0
(25)
.3
(6)
FR8 11.9
(301)
— 13.0
(330)
31.9
(810)
10.2
(258)
10.4
(265)
— — 1.3
(33)
.4
(9)
