Eaton SVX9000 Series - Enclosure Box B NEMA Type 12

June 2006
78
For more information visit: www.EatonElectrical.com CA04000006E
SVX9000 Adjustable Frequency Drives
VFD Pump Panels
Enclosure Box B NEMA Type 12
Figure 36. NEMA Type 12 SVX9000 Pump Application Drive Dimensions
Table 126. NEMA Type 12 SVX9000 Pump Application Drive Dimensions
Voltage
AC
hp
(I
H
)
hp
(I
L
)
Approximate Dimensions in Inches (mm) Approx.
Weight
Lbs. (kg)
Approx.
Ship
Weight
Lbs. (kg)
H H1H2W W1D D1
Three-Phase
208V 15 – 25 20 – 30 40.00
(1016.0)
38.00
(965.2)
36.35
(923.3)
20.92
(531.4)
19.30
(490.2)
16.76
(425.7)
2.34
(59.4)
185
(84)
229
(104)
230V 15 – 25 20 – 30
480V 30 – 60 40 – 75
Single-Phase
230V — 15 – 20 40.00
(1016.0)
38.00
(965.2)
36.35
(923.3)
20.92
(531.4)
19.30
(490.2)
16.76
(425.7)
2.34
(59.4)
185
(84)
229
(104)
480V — 25 – 30
4.00 (101.6)
Minimum Free Air
Space Required
H2H1
H
3.00 (76.2)
Minimum Air
Space
Required
Both Sides
D
D1
W1
W
0.44 (11.2)
Mounting
Holes
(4 Places)
