Eaton SVX9000 Series - Enclosure Box C NEMA Type 12

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
79
SVX9000 Adjustable Frequency Drives
VFD Pump Panels
Enclosure Box C NEMA Type 12
Figure 37. NEMA Type 12 SVX9000 Pump Application Drive Dimensions
Table 127. NEMA Type 12 SVX9000 Pump Application Drive Dimensions

Consult factory.
Voltage
AC
hp
(I
H
)
hp
(I
L
)
Approximate Dimensions in Inches (mm) Approx.
Ship
Weight
Lbs. (kg)
H H1H2H3H4W W1D D1
Three-Phase
208V 30 – 50 40 – 60 52.00
(1320.8)
50.00
(1270.0)
48.35
(1228.1)
72.00
(1828.8)
71.19
(1808.2)
30.92
(785.4)
29.30
(744.2)
16.78
(426.2)
2.34
(59.4)

230V 30 – 50 40 – 60
480V 75 – 125 100 – 150
Single-Phase
230V — 25 – 40 52.00
(1320.8)
50.00
(1270.0)
48.35
(1228.1)
72.00
(1828.8)
71.19
(1808.2)
30.92
(785.4)
29.30
(744.2)
16.78
(426.2)
2.34
(59.4)

480V — 40 – 60
3.00 (76.2)
Minimum Air Space
Required Both Sides
4.00 (101.6) Minimum
Free Air Space Required
H3
H2
H4
W
D1
W1
D
0.44 (11.2)
Mounting
Holes
(4 Places)
3.00 (76.2)
Minimum Air Space
Required Both Sides
4.00 (101.6) Minimum
Free Air Space Required
H
H2H1
D1
W
W1
D
0.44 (11.2)
Mounting
Holes
(4 Places)
