Eaton SVX9000 Series - Enclosure Box B NEMA Type 3 R

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
81
SVX9000 Adjustable Frequency Drives
VFD Pump Panels
Enclosure Box B NEMA Type 3R
Figure 39. NEMA Type 3R SVX9000 Pump Application Drive Dimensions
Table 129. NEMA Type 3R SVX9000 Pump Application Drive Dimensions
Voltage
AC
hp
(I
H
)
hp
(I
L
)
Approximate Dimensions in Inches (mm) Approx.
Weight
Lbs. (kg)
Approx. Ship
Weight
Lbs. (kg)
H H1 H2 H3 W W1 W2 W3 D D1 D2
Three-Phase
208V 15 – 25 20 – 30 46.09
(1170.7)
44.45
(1129.0)
42.77
(1086.4)
36.35
(923.3)
26.31
(668.3)
20.92
(531.4)
19.30
(490.2)
2.69
(68.3)
17.74
(450.6)
16.76
(425.7)
3.31
(84.1)
235
(107)
290
(132)
230V 15 – 25 20 – 30
480V 30 – 60 40 – 75
Single-Phase
230V — 15 – 20 46.09
(1170.7)
44.45
(1129.0)
42.77
(1086.4)
36.35
(923.3)
26.31
(668.3)
20.92
(531.4)
19.30
(490.2)
2.69
(68.3)
17.74
(450.6)
16.76
(425.7)
3.31
(84.1)
235
(107)
290
(132)
480V — 25 – 30
H3
H2
H1
H
W2
W1
D2
W 3
D1
DW
0.44 (11.2)
Mounting
Holes
(4 Places)
