Eaton SVX9000 Series - Enclosure Size 8

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
63
SVX9000 Adjustable Frequency Drives
Enclosed Drives
Enclosure Size 8
Table 94. Approximate Dimensions and Shipping Weight — Enclosed Products
Table 94. Approximate Dimensions and Shipping Weight — Enclosed Products (Continued)
Figure 31. Approximate Dimensions
Enclosure
Size
Dimensions in Inches (mm)
Wide
A
High
B
Deep
C
Mounting H Min. Air Space
D D1D2E F G G1 J K
8 48.0
(1219)
90.0
(2286)
24.0
(610)
42.2
(1072)
3.0
(77)
———5.5
(139)
— 84.4
(2143)
4.0
(102)
—
Enclosure
Size
Dimensions in Inches (mm) Max.
Approx.
Ship. Wt.
lbs. (kg)
Cable Entry U V W RR SS TT UU VV
LMNPRST
8 9.5
(241)
37.5
(952)
12.5
(318)
7.7
(196)
8.3
(210)
1.3
(32)
31.0
(787)
21.5
(545)
21.3
(541)
— 93.5
(2375)
————2000 (908)
T
S
LM
.56 (14.2) Dia.
Mounting Hole –
(4 Places)
R
RR
H
B
UV
C
A
For Top Cable Entry –
(2 Places)
Openings Filtered
for NEMA 12 Design
Bottom View
Top Vie w
Front View
Side View
For Bottom
Cable Entry
N
P
F
G
J
D
D1
I
L
hp
300
350
400
500
550
600
I
H
hp
250
300
350
400
500
550
480V
Note: See Page 51 notes 4
and 5 for enclosure and
option selection.
