Eaton SVX9000 Series User Manual

June 2006
CA04000006E For more information visit: www.EatonElectrical.com
5
SVX9000 Adjustable Frequency Drives
Open Drives
Technical Data and Specifications
Table 2. SVX9000 Specifications
Table 3. Standard I/O Specifications
Description Specification
Input Ratings
Input Voltage (V
in
) +10% / -15%
Input Frequency (f
in
) 50/60 Hz (variation up to 45 – 66 Hz)
Connection to Power Once per minute or less (typical
operation)
High Withstand Rating 100 kAIC
Output Ratings
Output Voltage 0 to V
in
Continuous Output
Current
I
H
rated 100% at 122°F (50°C), FR9 and below
I
L
rated 100% at 104°F (40°C), FR9 and below
I
H
/I
L
100% at 104°F (40°C), FR10 and above
Overload Current (I
H
/I
L
) 150% I
H
, 110% I
L
for 1 min.
Output Frequency 0 to 320 Hz
Frequency Resolution .01 Hz
Initial Output Current (I
H
) 250% for 2 seconds
Control Characteristics
Control Method Frequency Control (V/f)
Open Loop: Sensorless Vector Control,
Closed Loop: SPX9000 Drives Only
Switching Frequency
Frame 4 – 6
Frame 7 – 12
Adjustable with Parameter 2.6.9
1 to 16 kHz; default 10 kHz
1 to 10 kHz; default 3.6 kHz
Frequency Reference Analog Input: Resolution .1% (10-bit),
accuracy ± 1% V/Hz
Panel Reference: Resolution .01 Hz
Field Weakening Point 30 to 320 Hz
Acceleration Time 0 to 3000 sec.
Deceleration Time 0 to 3000 sec.
Braking Torque DC brake: 30% x T
n
(without brake option)
Ambient Conditions
Ambient Operating
Temperature
14°F (-10°C), no frost to 122°F (+50°C) I
H
(FR4 – FR9)
14°F (-10°C), no frost to 104°F (+40°C) I
H
(FR10 and up)
14°F (-10°C), no frost to 104°F (+40°C) I
L
(all frames)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Relative Humidity 0 to 95% RH, noncondensing,
non-corrosive, no dripping water
Air Quality Chemical vapors: IEC 721-3-3, unit in
operation, class 3C2; Mechanical particles:
IEC 721-3-3, unit in operation, class 3S2
Altitude 100% load capacity (no derating) up to 3280
ft. (1000m); 1% derating for each
328 ft. (100m) above 3280 ft. (1000m);
max. 9842 ft. (3000m)
Vibration EN 50178, EN 60068-2-6; 5 to 50 Hz,
Displacement amplitude 1 mm (peak) at
3 to 15.8 Hz, Max. acceleration amplitude 1G
at 15.8 to 150 Hz
Shock EN 50178, EN 60068-2-27 UPS Drop test (for
applicable UPS weights) Storage and ship-
ping: max. 15G, 11 ms (in package)
Enclosure Class NEMA 1/IP21 or NEMA 12/IP54,
Open Chassis/IP20
Description Specification
Standards
Product IEC 61800-2
Safety UL 508C
EMC (at default settings) Immunity: Fulfills all EMC immunity require-
ments; Emissions: EN 61800-3, LEVEL H
Control Connections
Analog Input Voltage 0 to 10V, R = 200 k1 (-10 to 10V joystick con-
trol) Resolution .1%; accuracy ±1%
Analog Input Current 0(4) to 20 mA; R
i
- 2501 differential
Digital Inputs (6) Positive or negative logic; 18 to 30V DC
Auxiliary Voltage +24V ±15%, max. 250 mA
Output Reference Volt-
age
+10V +3%, max. load 10 mA
Analog Output 0(4) to 20 mA; R
L
max. 5001; Resolution
10 bit; Accuracy ±2%
Digital Outputs Open collector output, 50 mA/48V
Relay Outputs 2 programmable Form C relay outputs
Switching capacity: 24V DC / 8A,
250V AC / 8A, 125V DC / 0.4A
Protections
Overcurrent Protection Trip limit 4.0 x I
H
instantaneously
Overvoltage Protection Yes
Undervoltage Protection Yes
Earth Fault Protection In case of earth fault in motor or motor cable,
only the frequency converter is
protected
Input Phase Supervision Trips if any of the input phases are
missing
Motor Phase Supervision Trips if any of the output phases are
missing
Overtemperature
Protection
Yes
Motor Overload
Protection
Yes
Motor Stall Protection Yes
Motor Underload
Protection
Yes
Short Circuit Protection Yes (+24V and +10V Reference Voltages)
Description Specification
6 – Digital Input Programmable 24V: “0” ) 10V, “1” * 18V,R
i
> 5 k⏲
2 – Analog Input Configurable
w/Jumpers
Voltage: 0 – ±10V, R
i
> 200 k⏲
Current: 0 (4) – 20 mA, R
i
= 250 k⏲
2 – Digital Output Programmable Form C Relays 250V AC 2 Amp or
30V DC2 Amp resistive
1 – Digital Output Programmable Open collector 48V DC 50 mA
1 – Analog Output Programmable
Configurable w/Jumper
0 – 20 mA, R
L
< 500 ohms,
resolution 10 Bits/0.1%

Eaton SVX9000 Series Specifications

General

Communication Protocols	Modbus RTU, CANopen
Protection Features	Overcurrent, Overvoltage, Short Circuit, Over Temperature
Cooling Method	Forced Air Cooling
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
