Eaton SVX9000 Series User Manual

June 2006
80
For more information visit: www.EatonElectrical.com CA04000006E
SVX9000 Adjustable Frequency Drives
VFD Pump Panels
Enclosure Box A NEMA Type 3R
Figure 38. NEMA Type 3R SVX9000 Pump Application Drive Dimensions
Table 128. NEMA Type 3R SVX9000 Pump Application Drive Dimensions
Voltage
AC
hp
(I
H
)
hp
(I
L
)
Approximate Dimensions in Inches (mm) Approx.
Weight
Lbs. (kg)
Approx.
Ship
Weight
Lbs. (kg)
H H1H2H3W W1W2W3D D1D2
Three-Phase
208V 3/4 – 10 1 – 15 33.00
(838.2)
31.36
(796.5)
29.67
(753.6)
25.35
(643.9)
21.05
(534.7)
16.92
(429.8)
15.30
(388.6)
2.07
(52.6)
17.24
(437.9)
16.26
(413.0)
3.31
(84.1)
170
(77)
215
(98)
230V 3/4 – 10 1 – 15
480V 1 – 25 1 – 30
Single-Phase
230V — 3/4 – 10 33.00
(838.2)
31.36
(796.5)
29.67
(753.6)
25.35
(643.9)
21.05
(534.7)
16.92
(429.8)
15.30
(388.6)
2.07
(52.6)
17.24
(437.9)
16.26
(413.0)
3.31
(84.1)
170
(77)
215
(98)
480V — 3/4 – 20
H3H2H1
H
W2
W1 D2 W 3 D1
DW
0.44 (11.2)
Mounting
Holes
(4 Places)

Eaton SVX9000 Series Specifications

General

Communication Protocols	Modbus RTU, CANopen
Protection Features	Overcurrent, Overvoltage, Short Circuit, Over Temperature
Cooling Method	Forced Air Cooling
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
