SVX9000 Adjustable Frequency Drives
Open Drives
Figure 4. 9000X Dimensions, NEMA Type 1 and NEMA Type 12, FR7
Table 31. 9000X Drive Dimensions, FR7
W2
H1
D1
D2
Knockouts
R2 R2
R1
D3
H2
H3
W1
Frame
Size
Voltage hp (I
H
) Approximate Dimensions in Inches (mm) Weight
lbs. (kg)
Knockouts @ Inches (mm)
H1 H2 H3 D1 D2 D3 W1 W2 R1 dia. R2 dia. N1 (O.D.)
FR7 230V 20 – 30 24.8
(630)
24.2
(614)
23.2
(590)
10.1
(257)
3.0
(77)
7.3
(184)
9.3
(237)
7.5
(190)
.7
(18)
.4
(9)
77.2
(35)
3 @ 1.5 (37)
480V 40 – 60
575V 30 – 40
