High Frequency Vibration
High frequency vibration will show as a regular displacement of drops, without necessarily distorting
character height or width. The illustration below shows the displacement of rasters in response to
high frequency vibration:
Notice how characters
are distorted in width
as the product tilts
under the printhead
Product tilting from side to
side along the axis of
conveyor travel
Notice how characters
are distorted in height
in a sinusoidal form
Product tilting from side to side
at 90 degrees to the axis of
conveyor travel
