2 Menu 4-2 - Case controllers
The submenu for configuration of the case controllers is called using this button. All important
parameters and the status of the case controllers are displayed there. Case controllers can be added using the
"New entry" button. Already added case controllers can be selected and configured using the corresponding
screen.
The assigned CAN bus address, diverse statuses and operating statuses are also displayed.
Symbol Meaning
The status of the connection (communication) with the node is OK
The status of the connection (communication) with the node is unknown
The node has failed
The node has been unloaded
The status of the node is OK
The node has alarm status
The screen contains the following parameters:
Configuration Case Controllers Entry Default
Name Name of the node, e.g. Deep freeze island
site case
max. 19 characters -
Position Position designation of the node, e.g.
TK_01
5 characters -
Priority Alarm and message priority 0..99 0..99 -
Address CAN bus address 1..99 These fields cannot be edited! -
Serial number Serial number of the controller -
Firmware version Firmware version of the controller -
Integrated using The controller is connected to the system
centre via this interface
-
Pack number Pack membership for the pack -
Remote control using terminal mode
The terminal mode screen is opened using the Remote Control button. All parameters of the case controller can
be configured in the terminal mode. For more information, see chapter Remote control of E*LDS components
(terminal mode).
Any case controller can be removed from the system again using the "Delete" button. A case controller
can only be deleted if it has previously been switched off and accordingly signalled as failed!
