6.1.2 Handling wide COMBICON connector
Correct handling
Mating connectors must be plugged or unplugged vertically and without canting.
Incorrect handling
DANGER
Warning of dangerous electrical voltage! Danger to life - Danger of electric shock! For assembly,
the safety regulations and the work safety instructions must beobserved.All plug-in connections may
only be plugged and unplugged in a de-energised state.

For detailed information on handling wide COMBICON connectors, see online in EDP.

ATTENTION
Incorrecthandlingleadstodamagetotheplugsocket!Never detach the mating connector on one
side, as this will damage the pins of the plug socket!

