INSTRUCTIONS MANUAL
-22-
ENTER Enter symbol, to confirm
BACK Back symbol, to return back without confirm
STOP Stop symbol, to stop a phase
ARROW Arrow symbol, to move in the menu
STANDARD
RECOVERY
activates a menu that helps the user to perform a
recovery/recycling phase (without SAE J-2788 or SAE J-2843
compliance)
VACUUM activates a menu that helps the user to perform a vacuum phase
OIL / UV INJECTION
activates a menu that helps the user to perform a oil/uv injection
followed by a gas filling phase
GAS FILLING activates a menu that helps the user to perform a gas filling phase
A/C pressure check
activates A/C pressure check menu
NITROGEN TEST activates a menu that helps the user to perform a NITROGEN TEST
FLUSHING HOSES activates a menu that helps the user to perform a FLUSHING HOSES
A/C FLUSHING activates a menu that helps the user to perform a A/C FLUSHING
SETUP activates the setup menu of the service station
MAINTENANCE activates the maintenance menu of the service station
DATA
activates a menu that contains all the information of the
service station
Oil-
A/C pressure check
Flushing kit
Recovery
Vacuum
Charge
–
