Ecotechnics ECK FLAG - Fill the Rechargeable Container New Oil (Poe)

INSTRUCTIONS MANUAL
-94-
1
FIG. 28
i
FILL THE RECHARGEABLE CONTAINER NEW OIL
(POE)
Types of oil: use only oils recommended by the manufacturer or the vehicle manufacturer.
Always refer to the information provided by the manufacturer of the A / C system.
Never use used oil
Procedure:
1. press the quick coupling button (ref 1, Fig.28) and disconnect the oil container
OIL container (ref i, Fig.28);
2. remove the container from its housing
3. hold the container, and unscrew the cap (ref 2, Fig.26). fill the container (Fig.27) with the
correct quantity of compressor oil, of a correct type and grade.
4. Screw the cap (ref 2, Fig.26) back into the container.
5. Replace the container and hook it up to the quick connection taking care not to exert
pressure on the scale in order not to damage it.
NOTE: in order to reduce humidity and air contamination of UV, the collapsible container has to
be filled almost to the brim.
