Ecotechnics ECK FLAG - MAINTENANCE PROCEDURES; TANK FILLING PROCEDURE

INSTRUCTIONS MANUAL
-75-
MAINTENANCE
From the MAIN MENU:
Select the MAINTENANCE, the following screen will be displayed:
TANK FILLING
This operation must be performed whenever the available refrigerant fluid in the bottle is less
than 3 kg and must in any case be performed when the “empty bottle” alarm is displayed.
From MAINTENANCE, select TANK FILLING, the following screen will be displayed:
Use the keypad to insert the amount of refrigerant, then press to continue.
ECK FLAG
MAIN MENU
TANK PRESSURE PAG
6.32 BAR 136ml
TANK TEMPERATURE POE
17.9°C 110 ml
REFRIGERANT AVAILABLE UV H
2735 g 27ml
USED OIL
89 ml
DD/MM/YY XX:XX PM
DD/MM/YY XX:XX PM
MAINTENANCE
Tank filling
Air purge manual
Empty hoses
Services alarm
Services report
DD/MM/YY XX:XX PM
MAINTENANCE / TANK FILLING
CHARGE AMOUNT
(min 600 – 6979 max)
600
g
1
2
3
4
5
6
7
8
9
0
.
<
