INSTRUCTIONS MANUAL
-32-
AUTOMATIC PROCEDURE
In the automatic mode, all the operations are performed automatically: recovery and recycling,
oil discharge, vacuum, new oil reintegration, and charging. The values for the quantity of gas
recovered, quantity of oil recovered, vacuum time, quantity of oil reintegrated, and quantity of
gas charged into the system are automatically printed at the end of each single operation.
Connect the hoses to the A/C system with the quick-connect couplings bearing in mind that
BLUE must be connected to the low-pressure side and RED to high pressure. If the A/C
system is equipped with a single quick-connect coupling for high or low pressure, connect only
the relative hose.
From the MAIN MENU:
Select the AUTOMATIC PROCEDURE , the following screen is displayed :
Select the STANDARD VEHICLE or HYBRID VEHICLE the following screen will be
displayed:
OIL-UV INJECTION is disabled pressing
NOTE: When HYBRID VEHICLE is selected UV is disabled (except HYBRID UV).
DD/MM/YY XX:XX PM
MAIN MENU
TANK PRESSURE PAG
6.32 BAR 136ml
TANK TEMPERATURE POE
17.9°C 110 ml
REFRIGERANT AVAILABLE UV H
2735 g 27ml
USED OIL
89 ml
Injection setting
DD/MM/YY XX:XX PM
AUTOMATIC / OIL-UV INJECTION
DD/MM/YY XX:XX PM
AUTOMATIC / OIL-UV INJECTION
STANDARD VEHICLE HYBRID VEHICLE
