INSTRUCTIONS MANUAL
-55-
The nitrogen will be injected into the A/C system, the test will start as soon as the pressure is
stable:
If leaks are detected, the machine will give an alarm signal, discharge the nitrogen from the
system, and display a SYSTEM LEAKS alarm warning. If the test detects no leaks, the
machine will discharge the nitrogen:
Close external bottle and press to continue
then the machine will sound and alarm and the following screen will be displayed:
Disconnect coupling, then press the following screen will be displayed:
N2 test in progress
DD/MM/YY XX:XX PM
MANUAL / / NITROGEN TEST (N2)
N2 pressure
9.7 bar
05:41
Close external bottle and press to continue
DD/MM/YY XX:XX PM
MANUAL / / NITROGEN TEST (N2)
N2 discharge
DD/MM/YY XX:XX PM
MANUAL / / NITROGEN TEST (N2)
Disconnect N2 bottle and press to continue
DD/MM/YY XX:XX PM
MANUAL / / NITROGEN TEST (N2)
