INSTRUCTIONS MANUAL
-81-
10) Insert the new dryer filter, use the special wrench (ref Fig.16), Press
to continue with vacuum check:
automatically the machine proceeds to the pressure control
11) If no leaks are detected the following screen will be displayed:
12) Then After few minutes:
13) DRYER FILTER CHANGE is now successfully completed.
The service alarm procedure includes the VACUUM PUMP OIL CHANGE
Press to continue.
Check leaks with vacuum
DD/MM/YY XX:XX PM
MAINTENANCE / SERVICES ALARM / DRYER FILTER
Check leaks with pressure
DD/MM/YY XX:XX PM
MAINTENANCE / SERVICES ALARM / DRYER FILTER
DD/MM/YY XX:XX PM
Internal circuit gas removal
MAINTENANCE / SERVICES ALARM / DRYER FILTER
DD/MM/YY XX:XX PM
Unscrew the filling cap and the drain cap
than remove used oil from vacuum pump
and press to continue
MAINTENANCE / SERVICES ALARM / DRYER FILTER
