Chapter 11
| Interface Commands
Transceiver Threshold Configuration
– 442 –
Example
Console(config)interface ethernet 1/1
Console(config-if)#transceiver-threshold-auto
Console#
transceiver-threshold
current
This command sets thresholds for transceiver current which can be used to trigger
an alarm or warning message. Use the no form to restore the default settings.
Syntax
transceiver-threshold current {high-alarm | high-warning | low-alarm |
low-warning} threshold-value
no transceiver-threshold current
high-alarm – Sets the high current threshold for an alarm message.
high-warning – Sets the high current threshold for a warning message.
low-alarm – Sets the low current threshold for an alarm message.
low-warning – Sets the low current threshold for a warning message.
threshold-value – The threshold of the transceiver current.
(Range: 0-13100 in units of 0.01 mA)
Default Setting
High Alarm: 10.50 mA
HIgh Warning: 9.00 mA
Low Warning: 2.50 mA
Low Alarm: 2.00 mA
Command Mode
Interface Configuration (SFP/SFP+ Ports)
Command Usage
â—† If trap messages are enabled with the transceiver-monitor command, and a
high-threshold alarm or warning message is sent if the current value is greater
than or equal to the threshold, and the last sample value was less than the
threshold. After a rising event has been generated, another such event will not
be generated until the sampled value has fallen below the high threshold and
reaches the low threshold.
â—† If trap messages are enabled with the transceiver-monitor command, and a
low-threshold alarm or warning message is sent if the current value is less than
or equal to the threshold, and the last sample value was greater than the
threshold. After a falling event has been generated, another such event will not
be generated until the sampled value has risen above the low threshold and
reaches the high threshold.
