Chapter 50
| IP Routing Commands
Border Gateway Protocol (BGPv4)
– 1147 –
show ip bgp paths This command shows all paths in the database.
Syntax
show ip bgp paths
Command Mode
Privileged Exec
Example
Console#show ip bgp paths
Address RefCnt ASpath
0x331dad0:0 1
0x331d850:93 1 600
Table 27: show ip bgp - display description
Field Description
BGP neighbor IP address of neighbor.
remote AS Autonomous system number of the neighbor.
local AS Local autonomous system number.
external link “external link” is displayed for external BGP neighbors. “internal link” is
displayed for iBGP neighbors.
BGP version BGP version used to communicate with remote router.
remote router ID IP address of the neighbor.
BGP state Stage of session negotiation.
Last read Time since a message was last received from this neighbor.
hold time Time to maintain the session with this neighbor without receiving a
message.
keepalive interval Interval at which keepalive messages are transmitted to this neighbor.
Neighbor capabilities BGP capabilities advertised and received from this neighbor.
Message statistics Statistics organized by message type.
Minimum time
between
advertisement runs
Time between transmission of advertisements.
For address family Address family to which the following information refers.
Local host/port IP address and TCP port of the local BGP speaker.
Foreign host/port IP address and TCP port of the neighbor BGP speaker.
Nexthop IP address of next system via which packets are forwarded to the destination
network.
Read thread The read status for the socket connection with this neighbor.
Write thread The write status for the socket connection with this neighbor.
