Chapter 1
| Initial Switch Configuration
Connecting to the Switch
– 66 –
â—† Filter packets using Access Control Lists (ACLs)
â—† Configure up to 4094 IEEE 802.1Q VLANs
â—† Enable GVRP automatic VLAN registration
â—† Configure IP routing for unicast or multicast traffic
â—† Configure router redundancy
â—† Configure IGMP multicast filtering
â—† Upload and download system firmware or configuration files via HTTP (using
the web interface) or FTP/TFTP (using the command line or web interface)
â—† Configure Spanning Tree parameters
â—† Configure Class of Service (CoS) priority queuing
â—† Configure static or LACP trunks (up to 16)
â—† Enable port mirroring
â—† Set storm control on any port for excessive broadcast, multicast, or unknown
unicast traffic
â—† Display system information and statistics
â—† Configure any stack unit through the same IP address
Connecting to the
Console Port
The switch provides an RS-232 serial port that enables a connection to a PC or
terminal for monitoring and configuring the switch. A null-modem console cable is
provided with the switch.
Note:
When configuring a stack, connect to the console port on the Master unit.
Attach a VT100-compatible terminal, or a PC running a terminal emulation program
to the switch. You can use the console cable provided with this package, or use a
null-modem cable that complies with the wiring assignments shown in the
Installation Guide.
To connect a terminal to the console port, complete the following steps:
1. Connect the console cable to the serial port on a terminal, or a PC running
terminal emulation software, and tighten the captive retaining screws on the
DB-9 connector.
2. Connect the other end of the cable to the RS-45 serial port on the switch.
3. Make sure the terminal emulation software is set as follows:
â–
Select the appropriate serial port (COM port 1 or COM port 2).
â–
Set the baud rate to 115200 bps.
â–
Set the data format to 8 data bits, 1 stop bit, and no parity.
