Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 464 –
Console#show lacp 1 internal
Port Channel : 1
Admin Key : 0
Oper Key : 3
Timeout : Long
------------------------------------------------------------
Member Port : Eth 1/23
Periodic Time : 30 seconds
System Priority : 32768
Port Priority : 32768
Admin Key : 3
Oper Key : 3
Admin State : Defaulted, OUT_OF_SYNC, Aggregatable, Long Timeout,
Actvie LACP
Oper State : Distributing, Collecting, IN_SYNC, Aggregatable,
Long Timeout, Actvie LACP
.
.
.
Unknown Packet
Received
Number of frames received that either (1) Carry the Slow Protocols Ethernet
Type value, but contain an unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the Slow Protocols Ethernet
Type.
Illegal Packet Received Number of frames that carry the Slow Protocols Ethernet Type value, but
contain a badly formed PDU or an illegal value of Protocol Subtype.
Table 78: show lacp internal - display description
Field Description
Admin Key Current administrative value of the key for the aggregation port.
Oper Key Current operational value of the key for the aggregation port.
Timeout Time to wait for the next LACPDU before deleting partner port information.
Periodic Time Number of seconds before invalidating received LACPDU information.
System Priority LACP system priority assigned to this port channel.
Port Priority LACP port priority assigned to this interface within the channel group.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
â—†
Expired – The actor’s receive machine is in the expired state;
â—†
Defaulted – The actor’s receive machine is using defaulted operational
partner information, administratively configured for the partner.
â—†
Distributing – If false, distribution of outgoing frames on this link is
disabled; i.e., distribution is currently disabled and is not expected to be
enabled in the absence of administrative changes or changes in received
protocol information.
â—†
Collecting – Collection of incoming frames on this link is enabled; i.e.,
collection is currently enabled and is not expected to be disabled in the
absence of administrative changes or changes in received protocol
information.
â—†
Synchronization – The System considers this link to be IN_SYNC; i.e., it has
been allocated to the correct Link Aggregation Group, the group has been
associated with a compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and operational Key
information transmitted.
Table 77: show lacp counters - display description (Continued)
Field Description
