Edgetech 4125 Series User Manual

C-30 C.0 TOWING CHARACTERISTICS
4125 SIDE SCAN SONAR SYSTEM 0004823_REV_F
C.1.25 Config. 54: 4125, A302799 Cable - 100m Long
-110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 0
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
Tow Cable Shape & Tow Fish Position
Position Aft of Tow Vessel (m)
Depth (m)
Tow Cable - p/n A302799,
Length - 100m
Tow Fish - 4125 Telemetry
2 kts
3 kts
4 kts
5 kts
6 kts
0 20 40 60 80 100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
Tow Cable Length vs Depth
Cable Length (m)
Depth (m)
Tow Cable - p/n A302799,
Length - 100m
Tow Fish - 4125 Telemetry
6 kts
5 kts
4 kts
3 kts
2 kts
