Edgetech 4125 Series User Manual

3-12 3.0 SETUP AND ACTIVATION
4125 SIDE SCAN SONAR SYSTEM 0004823_REV_F
Figure 3-8: Depressor Wing bracket shown attached to tow fish bracket
4. Secure depressor recovery cable to the rear handle of the towfish and secure with seizing wire or
Tie-wrap.
Figure 3-9: Depressor Wing Recovery Cable Attached to Towfish Rear Handle.
5. Verify that the tow cable connector on the towfish and the mating female connector on the tow
cable are free of corrosion or dirt.
6. Apply a thin film of silicone grease to the pins of the tow cable connector on the towfish.
