5-24 5.0 TROUBLESHOOTING
4125 SIDE SCAN SONAR SYSTEM 0004823_REV_F
ASSY SUB CABLE POWER AC 4125P, 0002868 (DWG. B958608)
ASSY CABLE 4125 DC POWER, 0014945
LAPTOP PC DI EDGETECH, 0009897
ASSY SUB CABLE 4125 PORTABLE RJ45 (IP67) TO RJ45 (STD) 10FT, 0014950
PCB ASSY TOP POWER SEP 4125 TOPSIDE, 0008564
MODEM VDSL2 4125 TOPSIDE, 0009238
Table 5-3: Part Numbers for Major 4125-P Topside Processor Components
5.9 Part Numbers for Major Towfish Components
The major 4125 Towfish components and their part numbers are listed below:
NOSE END CAP 4125 LT SS, 0008546
TUBE FRONT 4125 GEN2 SS, 0007540
TAIL CONE ONE PIECE 4125, 0009334
THUMBSCREW 4125 TAIL END CAP 316 SS, 0007545
HARDWARE WASHER STD 0.562 INCH ID 1.375 INCH OD RUBBER, 0007197
RAIL TOW LONG 4125 SHORT CABLE 316 SS, 0008370
RAIL TOW SHORT 4125 SHORT CABLE 316 SS, 0008371
PIN SHEAR 4125 TOW FISH 0.25 INCH DIA DELRIN, 0007538
HARDWARE SHACKLE BOW 5/16 SB 216 316 SS, 0006635
DUCER SIDE SCAN RX-SP 400-850 KHZ 4125 SP 300M, 0008529
DUCER SIDE SCAN RX-SP 540-1600 KHZ 4125 SP 300M, 0007559
ASSY CABLE 4125 EXTENSION POWER/TELEMETRY, 0008531
ASSY KIT ACCESSORY 4125, 0007606
ASSY SUB CABLE RECOVERY 4125 LT 23 INCH, 0007696
GROMMET,PUSH-IN,.5"ID,1-1/16OD, 0007728
ASSY SONARPRO 4125 LT 400-900 KHZ, 0007831
ASSY SONARPRO 4125 LT 600-1600 KHZ, 0007832
ASSY SONARPRO 4125 400-900 KHZ, 0007580
ASSY SONARPRO 4125 600-1600 KHZ, 0007691
CONN DUMMY PLUG WETMATE 06 POS FEMALE, 0003869
CONN LOCKING SLEEVE CIRC FEMALE BLACK MCDLS-FMCDLS-F, 0004065
HARDWARD SHACKLE ANCHOR 4125 316 SS, 0006633
KONTRON CPU MBT10 E3815 PASSIVE HEAT SINK, 0016958
