Edgetech 4125 Series User Manual

2-2 2.0 SPECIFICATIONS
4125 SIDE SCAN SONAR SYSTEM 0004823_REV_F
4125 PORTABLE TOPSIDE
4125 RACK MOUNT TOPSIDE
Operating relative
humidity:
0–80% (non-condensing)
0–80% (non-condensing)
Non-operating storage
relative humidity:
0–100%
0-100%
AC input power:
90–260 VAC, 50/60 Hz, 72–110
watts operating, auto switching
0.7 A/1.3 A at 120 VAC
idling/operating
0.3 A/0.56 A at 240 VAC
idling/operating
90–260 VAC, 50/60 Hz, 72–110 watts
operating, auto switching
0.6 A/1.1 A at 120 VAC
idling/operating
0.3 A/0.56 A at 240 VAC
idling/operating
DC input power:
12–24 VDC, 72 watts operating
4.3 A/6.0 A at 12 VDC
idling/operating
2.4 A/3.3 A at 24 VDC
idling/operating
N/A
Power to towfish:
75 VDC at 1.7 A max
75 VDC at 1.7 A max
Processor:
Intel Pentium M 730, 2.4 GHz
N/A
Memory:
2 GB
N/A
Data storage:
500 GB SATA, 6.0 Gb/s
N/A
Operating system:
Windows 7
N/A
Application software:
DISCOVER 4125
DISCOVER 4125
(on user-supplied computer)
Display:
15.4-inch LCD
N/A
Keyboard:
Laptop keyboard
N/A
Pointing device:
Laptop mouse pad
N/A
Wireless ETHERNET:
Centrino 802.11b
N/A (wired ETHERNET connection
only)
Towfish interface:
VDSL Modem link
VDSL Modem link
Table 2-1: 4125-P Portable Topside Processor
2.1.1 Technical Descriptions of Internal Components
This section provides an overall general description of the hardware elements comprising the 4125-P
Portable and 4125 Rack Mount Topside Processors of the 4125 Series Dual-frequency Side Scan Sonar
System. This information, which includes printed circuit board summary descriptions, chassis photos,
component call-outs, and a wiring diagram, can be useful for troubleshooting purposes and installing
optional equipment. The 4125 Towfish is considered non-user-serviceable and therefore specific
