Figure 2-4: 4125 Portable Topside Processor Chassis
Power board
(under panel)
Power Separation
board
VDSL Modem
board
15-amp fuse
AC Line Filter
(under panel)
Power Supply
Wireless
Bridge /
ETHERNET
Switch board
