Edgetech 4125 Series User Manual

2-12 2.0 SPECIFICATIONS
4125 SIDE SCAN SONAR SYSTEM 0004823_REV_F
SPECIFICATION
VALUE
Along track resolution:
80 cm @ 100 m (400 kHz)
58 cm @ 100 m (600 kHz)
40 cm @ 50 m (400 kHz)
29 cm @ 50 m (600 kHz)
24 cm @ 50 m (900 kHz)
20 cm @ 25 m (400 kHz)
14 cm @ 25 m (600 kHz)
12 cm @ 25 m (900 kHz)
9 cm @ 25 m (1600 kHz)
Horizontal beam width:
0.46° (400 kHz)
0.28° (900 kHz)
0.33° (600 kHz)
0.20° (1600 kHz)
Vertical beam width:
50°
Side lobes:
<-36 dB
Transducer array depression angle:
Factory set at 33°, adjustable to 25°
Operating temperature:
0–45°C (32–113°F)
Heading accuracy:
1.0° RMS
Heading resolution:
0.1°
Pitch and roll accuracy:
0.1°
Pitch and roll resolution:
0.1°
Pressure sensor accuracy:
0.5% of depth when calibrated for 0 m
Pressure sensor working depth:
0–200 m
Pressure sensor tolerance:
>200 m
Navigation interfaces:
RS-232, NMEA0183
Options:
Keel Weight Kit
Depressor Wing Kit
HullScan Kit
VerticalScan Kit
Magnetometer Interface
Table 2-2: Towfish Specifications
