Figure 3-2: 4125 Rack Mount Front Panel—Controls and Indicators
Figure 3-3: 4125 Rack Mount Back Panel—Controls and Connections
POWER
indicator
FISH POWER
indicator
LINK
indicator
CM
indicator
POWER
switch
POWER
connection & switch
DATA
connection (to PC)
SEA CABLE
connection (to fish)
