Edirol PC-80 - System Settings - Sample Rate Configuration; Sample Rate Setting Procedure

85
System settings for the PC-80
fig.audiosys-1
fig.util*
1
Simultaneously press the MIDI CH button and PGM CHANGE button,
and hold them down for a few moments.
The PC-80’s display will indicate “UTL,” and you will be in Utility mode.
fig.sy0
2
Press the [AUDIO SYSTEM] key on the keyboard.
“AS0” appears (blinking) in the display.
3
Use the VALUE encoder or the [0] key of the keyboard to choose “ AS0 .”
fig.enter
4
Press the ENTER button.
* If you press any other button without pressing the ENTER button, the setting will be
cancelled.
5
Use the VALUE encoder or the [0]–[3] keys of the keyboard to specify the sample rate for USB
audio.
6
Press the ENTER button.
* The Sample Rate setting will be applied the next time you turn on the power.
SAMPLE RATE SETTING
Key Indication Setting
0
44.1 kHz
1 48 kHz
2 96 kHz playback
3 96 kHz recording
2143
