Chapter 3: Configuration and Commissioning
ModuLaser Modular Aspirating Smoke Detector Installation Manual 59
The configurable options for the output functionality are shown in the table below.
Table 22: Output functionality
Description
The output activates when the applicable device or devices
any alarm state.
The output activates when the applicable device or devices are in
Alert/Aux. Alarm state.
The output activates when the applicable device or devices are in
Prealarm state.
The output activates when the applicable device or devices are in
Fire Alarm state.
The output activates when the applicable device or devices are in
Fire Alarm 2 state.
The output deactivates
when the applicable device or devices are
in any fault state, disabled, or in test mode.
This behaviour is opposite to outputs configured with any other
function.
The output activates when the applicable device or devices are in
Battery Fault state.
The output activates when the applicable
Mains Fault state.
The output activates when the applicable device or devices are in
Power Supply Fault state.
The output activates when the applicable device or devices are in
Flow Fault state.
The output activates when the applicable device or devices are in
Filter Blocked fault state
The output activates when the applicable device or devices are in
Filter Removed fault state.
The output activates when the applicable device or devices are in
Laserhead Fault state.
The output activates when the applicable device or devices are in
Fan Fault state.
The output activates when the applicable device or devices are in
Cover Removed fault state.
The output activates when the applicable device or devices are in
any Warning state.
The output activates when the applicable device or devices are
disabled.
The output activates when the applicable device or
any Test state.
