Edwards nEXT200200 - Pumping Media and Materials

Figure 4 nEXT200200 dimensions (mm)
CS/5277/A
10
293.2
Ø159.4
134.1
10.9
237
201.2
131
105.4
226
80.2
160
51.2 51.251.251.2
3
4
2
1
9
6
8
7
5
1. Envelope vent 2. LED indicators on drive unit
3. Booster port B 4. Removable cap RS485/RS232 switch vent
v
alve socket
5. Booster port A 6. Base mounng holes and fan mounngs
7. Earth point 8. Electrical drive unit
9. Body purge port 10. Backing port
1. Envelope vent 2. LED indicators on drive unit
3. Booster port B 4. Removable cap RS485/RS232 switch vent
valve socket
5. Booster port A 6. Base mounng holes and fan mounngs
7. Earth point 8. Electrical drive unit
9. Body purge port 10. Backing port
Page 21
B85200880_D - Technical data
