Edwards pXH6000 User Manual

© Edwards Limited 2012. All rights reserved. Page 13 Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
M561-00-880 Issue C
†
The minimum geometric wire gauge for Han® 100A module is 10mm² and minimum AWG size is 6 AWG
Table 7 - Electrical data iXL250Q, iXL500Q/R and iXL750Q/R (continued)
Characteristics iXL250Q iXL500Q iXL500R iXL750Q iXL750R Units
Dry pump motor rating 7.5 11 11 22 22 kW
Mechanical booster motor rating 4.5 7.5 7.5 7.5 705 kW
Current rating (200 - 230 V systems) 38 75 63 140 135 A
Current rating (380 - 460 V systems) 20 40 32 78 74 A
Recommended branch circuit fuse UL (200 - 230 V
systems)
50 100 80 170 160 A
Recommended branch circuit fuse IEC (200 - 230 V
systems)
35 80 65 140 135 A
Recommended branch circuit fuse UL (380 - 460 V
systems)
25 50 40 95 90 A
Recommended branch circuit fuse IEC (380 - 460 V
systems)
20 50 35 80 75 A
Min cable size for 200 - 230 V systems (or corresponding
AWG size)
10 (8) 25 (4) 25 (4) 50 (1/0) 50 (1/0) mm
2
(AWG)
Min cable size for 380 - 460 V systems (or corresponding
AWG size)
6 (8)
*
10 (6)
†
10 (6)
†
25 (4) 25 (4) mm
2
(AWG)
Mains connector for 200 - 230 V systems Han
®
K 4/4 Han
®
100 A
module
Han
®
100 A
module
Han
®
200 A
module
Han
®
200 A
module
-
Mains connector for 380 - 460 V systems Han
®
K 4/4 Han
®
100 A
module
Han
®
100 A
module
Han
®
100 A
module
Han
®
100 A
module
-
