Table 5.3: Assignment of the DIP-switch combinations S10 – S20
* The detailed descriptions of the alarm sequences are as follows:
- No-first-up (new-value) reporting with 1-frequency flashing and single acknowledgement
and
- First-up reporting with 1-frequency flashing and single acknowledgement.
Detailed information on the alarm sequences can be found in the separate document for description
of the alarm sequences SM-MA-FB-UK-001.
5.3 Configuration of the relay groups
The DIP-switches of the relay groups (S30 – S38) have no function in these annunciator variants.
The relay groups are set as follows:
Relays are assigned 1:1 to the respective inputs.
If only 1 or 2 relay groups (8 relays each) are integrated (e.g. BSM48), these are assigned to
the first or the first two alarm groups (8 inputs each).
The relays are triggered input parallel.
The relays are not inverted.
For the BSM-P these settings can be changed in the parameterisation software.
5.4 Default settings
LED-colour - red for fault signalling and green for operation indication
Function input 1 - horn acknowledgement
Function input 2 - acknowledgement
Button 1 - horn acknowledgement
Button 2 - acknowledgement
Button 3 - lamp test
Button 4 - not assigned
Function relay 1 - collective report 1
Function relay 2 - not assigned
Function relay 3 - external horn
Function relay 4 - live-contact
Collective report - static / outputparallel
Horn - retriggerable by subsequent alarm, manual acknowledgement
Horn lock - none
Alarm sequence when S./2 is set
to OFF (fault signalling)
OFF - No-first-up*
ON - First-up*
Horn triggering for subsequent
alarms
OFF – Horn is retriggered
ON - Horn is not
retriggerable
OFF – Horn is
retriggered
Processing of the alarm group
(8 channels)
OFF – Fault signalling
(Flashing, red)
ON - Operation indication
(Steady light, green)
Normally open / normally closed
principle of the group (8 channels)
OFF – Normally open
ON - Normally closed
