1 Validity
The description covers BSM devices with the following options:
59
B
x
x
x
x
C
x
x
x
0
Number of reporting inputs
0
8
8 Reporting inputs
1
6
16 Reporting inputs *
2
4
24 Reporting inputs
3
2
32 Reporting inputs
4
0
40 Reporting inputs
4
8
48 Reporting inputs
Operating voltage
1
24 V AC/DC
2
48 - 60 V AC/DC
5
110 - 220 V AC/DC
Signal voltage
1
24 V AC/DC
3
48 - 60 V AC/DC
4
110 V AC/DC
H
125 V AC/DC
5
220 V AC/DC
LED-Colour
D
2-colour, adjustable (red, green)
Repeat relays
0
No internal repeat relays
R
8 relay outputs (for 8 way fault annunciator)
R
16 relay outputs (for 16 way fault annunciator)**
R
24 relay outputs (for 24 way fault annunciator)
R
40 relay outputs (for 40 way fault annunciator)
Redundant operating voltage
0
No additional power supply
1
24 - 60 V AC/DC
5
110 - 220 V AC/DC
59
B
C
0
Article number
* Also available in wide housing (96 x 192 mm)
** 16 way fault annunciator with integrated repeat relays only available in wide housing (96 x 192 mm)
Table 1.1: Matrix of BSM-C variants
