Parameterisation
Page 44 of 45 MSM-BSM2G-BA-UK-001
7.2 Repeat relays and IEC objects
7.2.1 Relays
Index (idx)
The index is a consecutive number which ensures that the original sequence is reproducible when
sorting the table according to certain contents.
Device number and relay
The column device number (0…3) indicates the device that is addressed (master annunciator (0) or
one of the up to three slaves (1…3)).
The column relay addresses the respective repeat relay on the respective device.
The values entered in these columns have to be consistent.
Input
Input indicates the signal input which triggers the relay. The inputs 1…24 can be assigned to a repeat
relay. Additionally, the triggering of an external horn (“h”, “H”) or the output of the collective reports 1 –
3 (“s1…s3”, “S1…S3”) can be assigned to a repeat relay. Triggering input and repeat relay have to be
on the same device.
These fields must not be empty.
Pulse length
The pulse length is an integer value between 10 and 10000 in ms.
These fields must not be empty.
Selective functions
In the columns “active”, “inverted”, “output parallel” and “IEC-interface”, the respective function can be
activated by entering “x” or “X”.
For empty fields the respective function is not activated.
The name of the tab „EES_Relay“ must not be changed, otherwise the tab will not be
processed during the import.
