EKF SC3-LARGO - Power Requirements

User Guide • SC3-LARGO • CompactPCI
®
Serial CPU Board • Intel
®
Core
TM
5xxx Processor
Power Requirements
Power Requirements
Board
Load Current [A] at +12V (±5%)
Maximum Performance
LFM / HFM / Turbo
1)
Windows 8 Idle
LFM / HFM / Turbo
1)
SC3-63XX 1.8 / 4.0 / 4.0
2)
1.2 / 1.2 / 1.2
2)
SC3-84XX tbd / tbd / tbd
2)
tbd / tbd / tbd
2)
Load Current [A] at +5V[STDBY] (±5%)
3)
Full On / Sleep / Hibernate / Soft Off
(S0 / S3 / S4 / S5)
0 / 0 / 0 / 0.1
1)
Intel SpeedStep Frequence Modes LFM: Low Frequency Mode, HFM: High Frequency Mode.
2)
Add 10/100mA (link only/active) @1Gbps per Ethernet Port.
3)
This power supply is optional. It can be left open if not available.
© EKF -15- ekf.com
