User Guide • SC3-LARGO • CompactPCI
®
Serial CPU Board • Intel
®
Core
TM
5xxx Processor
CoolConduct
®
Heat Spreader
CoolConduct
®
Heat Exchange Technology (Option)
CoolConduct
®
is a special technology developed
by EKF and partners for optimum cooling of
card slots, by means of a powerful heat
exchanger system. Any card slot will be cooled
down via flexible mounted skids, which match
the ridge of a suitable heat spreader on the
particular board.
Skids and heat spreaders are made up of
massive copper. The runners are overcoated
with a special substance for optimum heat
conduction. CoolConduct
®
allows to swap
boards easily. Several hundred Watts power can
be dissipated as required for industrial high
performance multiprocessing systems.
© EKF -57- ekf.com
