User Guide • SC3-LARGO • CompactPCI
®
Serial CPU Board • Intel
®
Core
TM
5xxx Processor
Manufacturer Mode Jumper (J-MFG)
The jumper J-MFG is used to bring the board into the manufacturer mode. This is necessary only on
board production time and should not used by customers. For normal operation the jumper should
be removed. The pin header J-MFG is not stuffed on the SC3-LARGO by default.
J-MFG Function
Jumper
Removed
1)
Normal operation
Jumper Installed Entering Manufacturer Mode
1)
This setting is the factory default
1
J-MFG
© EKF -79- ekf.com
