User Guide • SC3-LARGO • CompactPCI

Serial CPU Board • Intel

Core

5xxx Processor

Technical Features

Feature Summary

General

< PICMG

CompactPCI

Serial (CPCI-S.0) CPU card

< Form factor single size Eurocard (board dimensions 100x160mm

)

< Mounting height 3U

< Front panel width 4HP (8HP/12HP assembly with optional mezzanine side card)

< Front panel I/O connectors for typical system configuration (2 x USB3, 2 x Mini DisplayPort, 2 x GbE)

< Backplane communication via PCI Express

Gen3, SATA 6G, USB 3.0, Gigabit Ethernet

< Local mezzanine expansion option (side card), COTS and custom specific boards

Processor

< 5

Generation Intel

Core™ CPU (Broadwell H)

< i7-5850EQ • 4 Cores • 2.7GHz (TB 3.4GHz) • 47/37W TDP/cTDP • GT3e-6200 Intel

Iris™ Pro graphics

1GHz • 6MB LLC • vPRO™/AMT

< i7-5700EQ • 4 Cores • 2.6GHz (TB 3.4GHz) • 47/37W TDP/cTDP • GT2-5600 Intel

HD graphics 1GHz •

6MB LLC • vPRO™/AMT

Firmware

< Phoenix

UEFI (Unified Extensible Firmware Interface) with CSM*

< Fully customizable by EKF

< Secure Boot and Measured Boot supported - meeting all demands as specified by Microsoft

< Windows

, Linux and other (RT)OS' supported

< Intel

AMT supported (disabled by default, must be enabled via BIOS setup)

* CSM (Compatibility Support Module) emulates a legacy BIOS environment, which allows to boot a legacy operating system such

as DOS, 32-bit Windows and some RTOS'

Main Memory

< Integrated memory controller up to 24GB DDR3L 1600 +ECC

< DDR3L +ECC soldered memory up to 8GB

< DDR3L +ECC SO-DIMM memory module socket up to 16GB
