User Guide • SC3-LARGO • CompactPCI

Serial CPU Board • Intel

Core

5xxx Processor

On-Board Connectors & Sockets

P-EXP Utility EXPansion Interface Connector (LPC, USB, HD Audio, SMBus), interface to

optional side board

P-HSE High Speed Expansion Connector (3 x SATA, 4 x USB), interface to optional low

profile mezzanine module or side board

P-PCIE PCI Express

Expansion Interface Connector, interface to optional side board

P-DP3 Digital Display Interface Connector, interface to optional 3

DisplayPort on side

board

P1 CompactPCI

Serial Type A Connector

P2-P4 CompactPCI

Serial Type B Connectors

P5 CompactPCI

Serial Type C Connector

P6 CompactPCI

Serial Type D Connector

P-SODM 204-pin DDR3L ECC Memory Module SDRAM PC3L-12800 Socket (ECC SODIMM)

P-XDP CPU Debug Port

Connector populated on customers request only

Pin Headers

P-FPH Pin header suitable for Front Panel Handle switch cable harness

P-ISP PLD glue logic device programming connector, not populated

Jumpers

DS-P Switches to configure link width and speed on P-PCIE

J-GP Jumper to reset UEFI BIOS Setup to EKF Factory Defaults, IEEE 1588 Pulse per Second

Output

J-MFG Jumper to enter Manufacturing Mode, not populated

J-RTC Jumper to reset RTC circuitry (part of PCH), not populated
