Local PCI Devices
The following table shows the on-board PCI devices and their location within the PCI configuration
space. Several devices are part of the processor and platform controller hub QM87.
Bus # Device # Function
#
Vendor
ID
Device ID Description
0 0 0 0x8086 0x1614 Processor Host Bridge/DRAM
Controller
0 1 0 0x8086 0x1601 Processor PCI Express Controller
0 1 1 0x8086 0x1605 Processor PCI Express Controller
0 2 0 0x8086 0x1612 Processor Integrated Graphics Device
0 3 0 0x8086 0x160C Audio Controller
0 20 0 0x8086 0x8C31 USB xHCI Controller
0 22 0 0x8086 0x8C3A Intel ME Interface #1
0 22 1 0x8086 0x8C3B Intel ME Interface #2
0 22 2 0x8086 0x8C3C Intel ME IDE Redirection
0 22 3 0x8086 0x8C3D Intel ME Keyboard Text Redirection
0 25 0 0x8086 0x153A PCH Gigabit LAN NC1 (i217LM)
0 26 0 0x8086 0x8C2D USB EHCI Controller #2
0 27 0 0x8086 0x8C20 Intel High Definition Audio Controller
0 28 0 0x8086 0x8C10 PCH PCI Express Port 1
0 28 3 0x8086 0x8C16 PCH PCI Express Port 4
0 28 4 0x8086 0x8C18 PCH PCI Express Port 5
0 29 0 0x8086 0x8C26 USB EHCI Controller #1
0 31 0 0x8086 0x8C4F LPC Bridge
0 31 2 0x8086 0x8C01
0x8C03
0x1E07
SATA: Non-AHCI/Non-RAID (Ports 0-
3)
1)
SATA: AHCI Mode
1)
SATA: RAID Capable
2)
0 31 3 0x8086 0x8C22 SMBus Controller
0 31 5 0x8086 0x8C09 SATA: Non-AHCI/Non-RAID (Ports
4/5)
