User Guide • SC3-LARGO • CompactPCI

Serial CPU Board • Intel

Core

5xxx Processor

Feature Summary

Performance Rating

< Passmark 8.0 performance test (Windows 8.1/64, 16GB RAM, C47-MSATA mezzanine SSD storage module)

< SC3-630D (i7-5700EQ): Passmark rating 2975, CPU rating 8620

< SC3-830D (i7-5850EQ): Passmark rating 3271, CPU rating 9167

Graphics

< Integrated graphics engine, 3 symmetric independent displays

< 3D HW acceleration DX11.1, OpenCL 1.2, OpenGL 4.3, ES 2.0

< HW media acceleration DXVA 2, VAAPI

< HW video decode H264, SVC, AVC, MVC, MPEG-2, MJPEG, JPEG large frame support, VC-1, VP8

< HW video encode H264, SVC, AVC, MVC, MPEG-2

< Content protection PUMA, PAVP, HDCP

< Front panel options: Dual Mini-DisplayPort (mDP) or single VGA connector

< 3

DisplayPort connector via mezzanine side card optional

< DisplayPort™ 1.2 Multi-Stream Transport (MST) - display daisy chaining

< Max Resolution 4096 x 2304 @60Hz (any DisplayPort), 1920 x 1200 (VGA)

< 4k x 2k @24Hz supported for Blu-ray playback

< Integrated audio

Networking

< Up to 4 networking interfaces in total - 2 x front RJ45 GbE, 2 x backplane GbE via P6

< 1000BASE-T, 100BASE-TX, 10BASE-T connections

< Front port 1 - I217LM with Intel

AMT support

< Front port 2 - Intel

I210-IT -40°C to +85°C operating temperature GbE NIC w. integrated PHY

< Front port option M12 X-coded connectors (replacement for RJ45, requires 8HP front panel width)

< IPv4/IPv6 checksum offload, 9.5KB Jumbo Frame support, EEE Energy Efficient Ethernet

< IEEE 802.1Qav Audio-Video-Bridging (AVB) enhancements for time-sensivitive streams

< IEEE 1588 and 802.1AS packets hardware-based time stamping for high-precision time synchronization

< Backplane Gigabit Ethernet w. 2 x I210-IT NIC

Chipset

< Intel

QM87 Lynx Point Platform Controller Hub (PCH)

< 8 x PCIe Gen2 5GT/s

< 6 x SATA 6G

< 10 x USB2, 4 x USB3

< LPC, Audio, Legacy
