User Guide • SC3-LARGO • CompactPCI

Serial CPU Board • Intel

Core

5xxx Processor

Feature Summary

On-Board Building Blocks

< Additional on-board devices, PCIe

based

< 3 x Gigabit Ethernet controllers Intel

I210IT

< 1 x Gigabit Ethernet PHY Intel

I217LM

< IEEE 1588-2008 Precision Time Protocol including PPS and PPM signals supported

< PCIe Gen2 packet switch 16-lane 16-port PLX PEX8618

< SATA 6G RAID controller Marvell

88SE9230, ARM powered subsystem for host CPU offload

Security

< Trusted Platform Module

< TPM 2.0 for highest level of certified platform protection

< Infineon Optiga™ SLB 9665 cryptographic processor

< Conforming to TCG 2.0 specification

< AES hardware acceleration support by 5

Gen processor series (Intel

AES-NI)

Front Panel I/O (4HP)

< 2 x Gigabit Ethernet RJ45 (1 = PCH & I217LM - iAMT, 2 = I210IT)

< 2 x DisplayPort (from processor integrated HD graphics engine, mDP style receptacles, optional cable

connector retainer available)

< 2 x USB 3.0

CompactPCI

Serial Backplane Resources

< PICMG

CPCI-S.0 CPU card & system slot controller

< 16 x PCIe Gen3 8GT/s (2 links x 8 for two fat pipe slots, derived directly from the Intel

Core™ CPU

< 6 x PCIe Gen2 5GT/s (6 links x 1 for peripheral slots)

< 3 x SATA 6G (from PCH)

< 4 x SATA 6G (Marvell hardware RAID controller)

< 4 x USB2, 2 x USB3 (from PCH)

< 2 x Gigabit Ethernet (I210IT networking controllers)
