EKF SC3-LARGO - Local Expansion and Mass Storage Solutions; Environmental & Regulatory

User Guide • SC3-LARGO • CompactPCI
®
Serial CPU Board • Intel
®
Core
TM
5xxx Processor
Feature Summary
Local Expansion and Mass Storage Solutions
< Mezzanine side card connectors for optional local expansion
< P-EXP - 2 x USB 2.0 & Legacy (from PCH)
< P-DP3 - 3
rd
DisplayPort video (from Intel
®
Core™ CPU)
< P-HSE - 3 x SATA 6G & 4 x USB 2.0 (from PCH)
< P-PCIE - PCIe Gen2 5GT/s 1 link x 4 lanes (from on-board PCIe
®
switch)
< 4HP Low profile mezzanine module options
< CFast™ Card with C41-CFAST mezzanine module
< SATA 1.8-Inch Solid State Drive with C42-SATA mezzanine module
< Dual mSATA SSD with C47-MSATA mezzanine module
< Dual M.2/NGFF SATA SSD 2230 - 2280 size with C48-M2 mezzanine module
< Custom specific storage & I/O module design
< 8HP/12HP Mezzanine side card options
< SCS-TRUMPET - 3
rd
DisplayPort F/P connector, RS-232, 2 x USB3, on-board 2.5-Inch SATA SSD or 2 x
M.2/NGFF SATA SSD module sockets 2230 - 2280
< Variety of other side cards available
< Custom specific side card design
Environmental & Regulatory
< Suitable e.g. for industrial, transportation & instrumentation applications
< Designed & manufactured in Germany
< ISO 9001 certified quality management
< Long term availability
< Rugged solution
< Coating, sealing, underfilling on request
< Lifetime application support
< RoHS compliant
< Operating temperature 0°C to +70°C
< Operating temperature -40°C to +85°C (industrial temperature range) on request
< Storage temperature -40°C to +85°C, max. gradient 5°C/min
< Humidity 5% ... 95% RH non condensing
< Altitude -300m ... +3000m
< Shock 15g 0.33ms, 6g 6ms
< Vibration 1g 5-2000Hz
< MTBF 11.7 years (SC3-840D)
< EC Regulatory EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)
© EKF -13- ekf.com
