P-EXP
I/F Type Controller
LPC (Low Pin Count) PCH
HD Audio PCH
SMBus PCH (buffered)
2 x USB 2.0 PCH
P-HSE
I/F Type Controller
SATA1, SATA2, SATA3 PCH
4 x USB 2.0 PCH
P-PCIE
I/F Type Controller
PCI Express
®
Gen2 1x4 or 4x1 PE Switch
